Description
The SSA-160DP is a 160 W PA mixer amplifier designed to amplify audio in medium-sized venues such as halls, auditoriums, classrooms, shops, meeting spaces, or worship places. It combines mixing, amplification, and digital audio playback in one unit.
- 5 Mic & 2 Aux Inputs. With built-in Digital Player & Bluetooth Connectivity.
- Pre-amplifier and Line Output for connecting to a Booster Amplifier and for recording the program.
- Line Input for connecting the output from any external mixer or another Amplifier.
- A resettable circuit breaker for protection against overload and short circuit.
- Instant transfer to DC power (Car Battery) if AC power fails.
- Box Speaker/ Driver Unit selector switch. Bass boost is defeated at the Driver Unit position for safer operation of the driver units.
- 5 LED array for output level monitoring.
| POWER OUTPUT |
|
220 W MAX. 160 W RMS. |
|
| TONE CONTROL |
|
BASS, TREBLE |
|
| INPUT CHANNELS |
|
5 x Mic 0.SmV/ 4.7kQ, 2 x AUX l00mV/ 470KQ |
|
| DIGITAL PLAYER |
|
MP3 Player with USB, SD Card, BT connectivity |
|
| SIGNAL TO NOISE RATIO |
|
60dB |
|
| SPEAKER OUTPUTS |
|
4 ohms, 8 ohms, 70/100V |
|
|
| COOLING |
|
Force Cooling |
|
| FREQUENCY RESPONSE |
|
50-15,000Hz |
|
| POWER SUPPLY |
|
220N240V, 50/60Hz, DC:24V (2x12V Car Battery) |
|
| DIMENSIONS |
|
W390 x H145 x D320mm |
|
| WEIGHT |
|
12.50 KG |
|
|
|
|
|
