PENZA HD4401-A is a high-frequency tweeter speaker designed to deliver clear, sharp, and detailed treble output. It is suitable for professional audio systems, DJ speaker cabinets, PA systems, and sound reinforcement applications. The tweeter helps improve vocal clarity, high-frequency response, and overall sound brightness in speaker setups.
| Feature | Details |
|---|---|
| Power Capacity | 50W RMS |
| Nominal Impedance | 8 Ω |
| Frequency Response / Range | 1,500–18,000 Hz |
| Sensitivity | 106 dB/1W/1m or 110 dB (varies depending on the horn used) |
| Recommended Crossover | \(2.5\text{kHz}\text{ (}18\text{dB/octave slope)}\) |
| Throat Diameter | \(25.4\text{ mm (1″)}\) |
| Voice Coil Diameter | 44.4 mm |
| Voice Coil Material | Edge Wound Copper Clad Aluminium Ribbon Wire |
| Voice Coil Former | Resin Bonded Kapton |
| Diaphragm Material | Titanium |
| Magnet Material | Strontium Ferrite |
| Throat Coupling | 1-3/8″ 18 TPI (Throat Couple No.1) |
| Dimensions | ∅ 115 × H66 mm |
